Property | Value |
Tensile Strength | 10.3 MPa min. |
Elongation (%) | 200 min. |
Secant Modulus | 173 MPa min. |
Heat shock (250° C, 4 hrs.) | No cracking |
Longitudinal change (%) | +5% to –15% Max |
*For reference use only
Nominal Size | ID Minimum (As Supplied) | ID Maximum (After Recovery) | Wall Thickness Nom. (After Recovery) | ||||
Inches | MM | Inches | MM | Inches | MM | Spool Length (M) | |
1/16″ | 0.063 | 1.6 | 0.02 | 0.50 | 0.020 | 0.431 | 30 |
3/32″ | 0.093 | 2.3 | 0.03 | 0.76 | 0.021 | 0.508 | 30 |
1/8″ | 0.125 | 3.0 | 0.04 | 1.01 | 0.023 | 0.508 | 30 |
3/16″ | 0.187 | 4.7 | 0.06 | 1.52 | 0.026 | 0.660 | 30 |
1/4″ | 0.250 | 6.0 | 0.08 | 2.03 | 0.027 | 0.685 | 30 |
3/8″ | 0.375 | 8.9 | 0.12 | 3.04 | 0.031 | 0.787 | 30 |
1/2″ | 0.500 | 12.0 | 0.16 | 4.06 | 0.033 | 0.838 | 30 |
3/4″ | 0.750 | 18.7 | 0.24 | 6.09 | 0.039 | 0.990 | 30 |
1″ | 1.00 | 25.0 | 0.33 | 8.38 | 0.047 | 1.193 | 20 |
1.5″ | 1.50 | 38.1 | 0.50 | 12.7 | 0.050 | 1.270 | 20 |
2″ | 2.00 | 50.8 | 0.66 | 16.7 | 0.055 | 1.397 | 15 |
