IRRAX™ TAPE VZL - Heat-shrinkable tubing
Irradiated, Crosslinked, PVC Tape
SFP standard (R2-1300)
Product Overview
Category
Heat-shrinkable tubing
Material
Flexible flame retarded polyvinyl chloride
Shrink ratio
1 : 1
Shrink temperature
Continuous operating temperature
-30℃ to +105℃
Available colors
Black, Gray
Flammability
Flame Retarded
Printed surface text
Industry
Rail/Transit, Insulation and Protection, General Maintenance and Repair
Environmental compliance
RoHS/RoHS2
Specifications / Approvals
SFP standard (R2-1300)
Other
Basic Properties
| Property (Units) | Test Method | Requirement |
|---|---|---|
| Physical: | ||
| Tensile strength (N/19mm width) | ASTM D2671** | 29.4 min. |
| Elongation (%) | ASTM D2671** | 125 min. |
| Heat Resistance (120℃, 7 days) | ||
| Tensile strength (N/19mm width) | ASTM D2671** | 29.4 min. |
| Elongation (%) | ASTM D2671** | 100 min. |
| Heat shock (200℃, 0.5 hrs) | No cracking or melting | |
| Low temperature flex (-45℃, 1 hr) | No cracking | |
| Electrical: | ||
| Dielectric withstand voltage (1.0kV, 1min) |
UL 224 | No breakdown |
| Volume resistivity (ohm-cm) | ASTM D876 | 1.0 x 1012 min. |
**Tested on whole tape (not die cut). Test speed = 300mm/min.
*For reference use only
Sizes
| Standard Size | Thickness | Tape Width | Length | |||
|---|---|---|---|---|---|---|
| (mm) | (mm) | (m) | ||||
| 0.09 x 19 | 0.09+/- 0.02 | 19.0 +/- 1.0 | 30 min | |||
| 0.09 x 25 | 0.09+/- 0.02 | 25.0 +/- 1.0 | 30 min | |||
| Standard Colors: Black, Gray How to Order: (Type of material) (Size) (Color) Example: Irrax Tape VZL 0.09 x 19 Black |
||||||
