Property (Units) | Test Method | Requirement |
---|---|---|
Physical: | ||
Tensile strength (psi) | ASTM D638 | 1700 min. |
Elongation (%) | ASTM D638 | 300 min. |
Tensile strength after heat aging (psi) | At 120℃ for 24 hrs. | 1700 min. |
Elongation after heat aging (%) | At 120℃ for 24 hrs. | 270 min. |
Longitudinal change (%) | AMS-DTL 23053 | +5, -5 |
Deformation resistance (%) | At 140℃ under 28 psi | 60 min. |
Impact resistance | JIS C3004 | No cracking |
Brittle point (℃) | ASTM D746 | – 35 max. |
Chemical: | ||
Corrosion | AMS-DTL-23053 (121℃, 16 hrs.) | No corrosion |
Water absorption (%) | ASTM D570 | 0.2 max. |
Fluid resistance: | ||
H2S04 | At 23℃ for 24 hrs. | No cracking |
Na0H | At 23℃ for 24 hrs. | No cracking |
Brake Fluid | At 23℃ for 24 hrs. | No cracking |
*For reference use only
Nominal Size | Inside Diameter (As Supplied) | Inside Diameter (After Recovery) | Wall Thickness Nom (After Recovery) | |||
---|---|---|---|---|---|---|
inches | (mm) | inches | (mm) | inches | (mm) | |
6″ | 0.236 | 6.0 | 0.177 | 4.5 | 0.047 | 1.2 |
8″ | 0.315 | 8.0 | 0.240 | 6.1 | 0.051 | 1.2 |
10″ | 0.394 | 10.0 | 0.272 | 6.9 | 0.059 | 1.5 |
11.5″ | 0.433 | 11.0 | 0.272 | 6.9 | 0.059 | 1.5 |
12″ | 0.472 | 12.0 | 0.177 | 4.5 | 0.047 | 1.2 |
15″ | 0.591 | 15.0 | 0.394 | 10.0 | 0.055 | 1.4 |
Standard Colors: Black only Standard Package: Coiled lengths. (Cut to order also available, contact SEIP). How to Order: (Type of material) (Size) (Color) (Packaging) Example: O2 6 Black L |
