AS23053
UL 224
Property (Units) | Test Method | Requirement |
---|---|---|
Physical: | ||
Tensile strength (psi) | ASTM D638 | 1500 min. |
Elongation (%) | ASTM D638 | 200 min. |
Cold impact (-55℃, 4 hrs.) | ASTM D746 | No cracking |
Heat shock (250℃, 4 hrs.) | AMS-DTL-23053 | No cracking |
Secant modulus (psi) | ASTM D882 | 2.5 x 104 max. |
Longitudinal change (%) | AMS-DTL-23053 | +5, -15 |
Electrical: | ||
Dielectric strength (volts/mil) | ASTM D876 | 500 min. |
Volume resistivity (ohm-cm) | ASTM D876 | 1.0 x 1014 min. |
Chemical: | ||
Corrosion (175℃, 16 hrs.) | UL 224 | No corrosion |
Water absorption (%) | ASTM D570 | 0.5 max. |
Fluid resistance (23℃, 24 hrs.) | ||
Tensile strength (psi) | AMS-DTL-23053 | 1000 min. |
Flammability | UL 224 | Pass |
Shrink temperature, nominal | 110℃ |
Specification reference: UL 224, 125℃, 600V
File E75077 YDTU2, Cat. No. SUMITUBE 02B2S
AMS-DTL-23053/4, Class 2 except longitudinal change
*For reference use only
Nominal Size | Inside Diameter (As Supplied) | Inside Diameter (After Recovery) | Wall Thickness Nom (After Recovery) | |||
---|---|---|---|---|---|---|
inches | (mm) | inches | (mm) | inches | (mm) | |
1/8″ * | .125 | 3.2 | .062 | 1.6 | .026 | 0.70 |
3/16″ * | .187 | 4.8 | .093 | 2.4 | .026 | 0.70 |
1/4″ | .250 | 6.4 | .125 | 3.2 | .030 | 0.75 |
3/8″ | .375 | 9.5 | .187 | 4.8 | .030 | 0.75 |
1/2″ | .500 | 12.7 | .250 | 6.4 | .030 | 0.75 |
5/8″ * | .625 | 15.9 | .313 | 7.9 | .033 | 0.85 |
3/4″ | .750 | 19.1 | .375 | 9.5 | .035 | 0.90 |
1″ | 1.000 | 25.4 | .500 | 12.7 | .042 | 1.10 |
1-1/4″ * | 1.250 | 31.8 | .625 | 15.9 | .047 | 1.20 |
1-1/2″ | 1.500 | 38.1 | .750 | 19.1 | .047 | 1.20 |
2″ * | 2.000 | 50.8 | 1.000 | 25.4 | .053 | 1.35 |
Standard Colors: Black Standard Package: Spooled How to Order: (Type of material) (Size) (Color) (Packaging) Example: O2B2S 1/4 Black Spooled |
* Non SAE-Spec sizes
